Product Name : Male Crimp Terminal / .062"(1.58mm) WTW Connectors

Part Number: 56T

Category : Wire to Wire

Pitch : .145"(3.68mm)

Series : WTW3681

File : Download

Product Features

◆ Material: Brass
◆ Finished: Tin-Plated
◆ Wire range: #18 ~ #30 AWG
◆ Used in ALEX 7604, 7625, 7725 Housings

Series Specifications

◆ Current rating: 5A AC, DC
◆ Voltage rating: 250V AC, DC
◆ Insulation resistance: 1000MΩ min.
◆ Dielectric strength: 1500V AC/minute
◆ Ambient temperature range: -40°C ~ +125°C
