Category : Board to Board

Pitch : .118＂(3.00mm)

Series : BTB3001

File : Download

Product Features

◆ in 2 thru 24 circuits
◆ Material: LCP
◆ Tin-plated phosphor bronze pin
◆ Mates with ALEX 3050-N, 3052-N Headers
◆ UL File No.: E114003
◆ CSA File No.: LR86545

Series Specifications

◆ Current rating: 5A max. AC/DC
◆ Voltage rating: 250V AC(RMS) or DC
◆ Contact resistance: 10mΩ max.
◆ Dielectric strength: 1500V AC/minute
◆ Temperature rise: 30°C max.
　(carry rated current load)
