66T
66T

详细介绍

Category : Board-in Terminal

Pitch : .071"(1.80mm)

Series : BIT1800

File : Download

Product Features

◆ Material: Tin-plated phosphor bronze
◆ Wire range: #18 AWG
◆ Insulation diameter ∅ 3.05 max.
◆ Recommended P. C. Board hole diameter
 ∅ 1.8+0.1/-0mm
◆ Applicable P. C. Board thickness: 1.57mm

Series Specifications

◆ Secures wire to P. C. Board before wave soldering
◆ Rapid and economical means of hand wring
 P. C. Boards
◆ Wire solders directly to P.C Board
◆ No additional contact resistance
◆ Low profile
